Agile Robots Thor Series Cobots

One Robot Family for Different Workloads

The main strength of the Thor Series is that it covers several payload and reach classes through a shared platform. Thor 3 handles small components and precise light assembly, while Thor 7 offers more capacity without moving into a large, heavy robot. Thor 12 extends the working radius to 1,300 mm and increases the payload to 12 kg, making it better suited to machine tending and heavier handling. At the top of the announced range, Thor 20 provides a 20 kg payload and 1,700 mm reach for tasks such as palletizing and loading machinery.

Because the robots share a standardized programming approach, companies can select a model that matches each workstation while retaining a more consistent user experience. This can be useful when an automation project includes several stations with very different reach and payload requirements.

Applications

Agile Robots positions the Thor Series for assembly, quality inspection, dispensing, machine tending and material handling across industries such as automotive, electronics, manufacturing, machining, medical products, cosmetics and plastics.

Thor 3 is aimed at compact workstations and precise light assembly, while Thor 7 provides additional capacity for general assembly, automated production cells and loading or unloading operations.

Thor 7 Pro is the specialised force-controlled model. Its joint torque sensors, hand-guided teaching and 0.5 N relative force accuracy make it better suited to processes where the robot must maintain or detect contact force, such as polishing, insertion and force-sensitive assembly.

For larger components, Thor 12 combines a 12 kg payload with a 1,300 mm reach and is positioned for heavier assembly, machine tending and material handling. Thor 20 extends the family to 20 kg and 1,700 mm for loading, unloading, handling and palletising applications. The wider series is also promoted for quality inspection and dispensing.

Choosing the Right Thor Model

Model: Thor 3
Payload: 3 kg | Reach: 600 mm | Robot Weight: 14 kg | Repeatability: ±0.03 mm | Maximum TCP Speed: 1.8 m/s | IP Rating: IP20 | Base Diameter: ⌀143 mm
Best suited for: Precise light assembly, compact automation stations and applications with limited installation space.
Availability: Currently available only in the APAC region.

Model: Thor 7
Payload: 7 kg | Reach: 900 mm | Robot Weight: 32 kg | Repeatability: ±0.03 mm | Maximum TCP Speed: 3.1 m/s | IP Rating: IP54 | Base Diameter: ⌀206 mm
Best suited for: Medium-duty assembly, automated integration, loading and unloading, and applications requiring a good balance of speed and precision.

Model: Thor 7 Pro
Payload: 7 kg | Reach: 900 mm | Robot Weight: 38 kg | Repeatability: ±0.03 mm | Maximum TCP Speed: 2.5 m/s | IP Rating: IP54 | Base Diameter: ⌀200 mm | Force-Control Accuracy: 0.5 N
Best suited for: Force-sensitive assembly and contact-based processes that benefit from joint torque sensing, precise force control and hand-guided teaching.

Model: Thor 12
Payload: 12 kg | Reach: 1,300 mm | Robot Weight: 35 kg | Repeatability: ±0.05 mm | Maximum TCP Speed: 3.7 m/s | IP Rating: IP54 | Base Diameter: ⌀206 mm
Best suited for: Heavier assembly, machine tending and material handling where additional reach, payload and high operating speed are needed.

Model: Thor 20
Payload: 20 kg | Reach: 1,700 mm | Robot Weight: 72 kg | Repeatability: ±0.10 mm | Maximum TCP Speed: 2.8 m/s | IP Rating: IP54 | Base Diameter: ⌀252.5 mm
Best suited for: Heavy-duty loading and unloading, material handling and palletizing.

Thor Series Compared with Other Agile Robots Cobots

Thor Series:
Six axes | 3–20 kg payload | 600–1,700 mm reach
Best suited for: Buyers who want a scalable selection of robot sizes for conventional industrial automation, ranging from compact assembly to heavier handling and palletising. Thor 7 Pro is the dedicated force-controlled model within the family.

Yu 5 Industrial:
Six axes | 5 kg payload at 1,000 mm or 7 kg at 850 mm | Integrated intelligent camera and NPU
Best suited for: Vision-guided applications such as object recognition, flexible picking, quality inspection and manipulation where integrated perception is especially valuable. It also has torque sensors in all six axes and 0.5 N force-control accuracy.

Diana 7:
Seven axes | 7 kg payload | 923 mm reach | ±0.05 mm repeatability
Best suited for: Highly dexterous and force-sensitive applications requiring obstacle avoidance, complex arm postures or smooth movement in restricted spaces. Torque sensors are integrated into all seven axes, with force-control accuracy of 0.5 N.
