JAKA Pro Series Cobots

company logo for JAKA Robotics JAKA Robotics

Country: China

Year: 2022

Summary

JAKA Pro Series cobots are IP68-rated collaborative robot arms built for demanding industrial environments where dust, oil, water, and reliable operation matter.

Status: Commercially available

Operation: Collaborative

Robot Type / Domain: Multi/General-Purpose, Industrial

Tasks: Welding, loading and unloading, handling, polishing and grinding, packing, palletizing, machine tending

Technical Specifications (series range)

Reach: 954 to 1713 mm

Reach: 37.559 to 67.441 in

Payload: 5 to 16 kg

Payload: 11.023 to 35.274 lbs

Pose Repeatability: ± 23 to ± 79.7 mm

Pose Repeatability: ± 0.906 to ± 3.138 in

Weight: 23 to 79.7 kg

Weight: 50.706 to 175.708 lbs

Battery Operated? No, Tethered

Arm Type: Articulated, Collaborative

Number of Axes: 6 DoF

IP Rating: IP68

Mounting: Floor, Ceiling, Wall, Any desired angle

Footprint: N/A

Operating Temperature: -10 ℃ to 50 ℃

Operating Temperature: 14.000 ℉ to 122.000 ℉

Show more specs

Software: Programming: Graphic programming, drag/freedrive teaching, SRCI, offline programming, and graphical-device programming depending on source page wording

Controller & Computing: Size: 410 mm × 307 mm × 235 mm | Cabinet Weight: 15.4 kg to 18 kg

Power supply: 100–240 VAC, 50–60 Hz

Power Consumption: 350 W to 750 W, depending on model

No more specs to show.

Top 5+ Qualities (by addoobot)

What we find to be the top qualities of the JAKA Pro Series Cobots:

IP68 Protection: Designed for harsher industrial environments where dust, oil, water, and small particulates may be present.
Harsh-Environment Focus: JAKA positions the Pro Series as a cobot family for demanding working conditions, not just standard indoor automation.
Useful Payload Range: The series covers 5 kg, 12 kg, and 16 kg payload models, giving users a practical spread from lighter handling to heavier industrial tasks.
Long-Reach Option: The Pro16 reaches up to 1713 mm, making it the strongest option in this series for larger workspaces and longer-reach tasks.
Collaborative Flexibility: The Pro Series keeps the flexibility of a cobot while adding stronger environmental protection than JAKA’s standard general-purpose models.
Industrial Application Fit: The series is suitable for tasks such as welding, loading and unloading, handling, polishing and grinding, packing, and palletizing.
JAKA Ecosystem Fit: The Pro Series sits alongside JAKA’s broader cobot lineup, including Zu, S, AL, A, and Mini series, but its main standout feature is IP68 high protection.

Learn More

What Makes the JAKA Pro Series Different

The JAKA Pro Series is best understood as JAKA’s high-protection collaborative robot series. While many cobots are designed mainly for clean factory environments, the Pro Series is aimed at tougher conditions where the robot may need stronger protection against dust, liquids, oil, and other environmental challenges.

The biggest practical difference is the IP68 rating of the robot body. This makes the Pro Series different from JAKA’s more general-purpose cobot families, especially when the workspace is not perfectly clean or controlled. JAKA’s own product page describes the Pro Series as offering “IP68 high protection” for complex environments, and the company timeline says the series was launched for harsh working conditions.

The series is also more focused than some of JAKA’s wider cobot ranges. Instead of covering many payload sizes, the Pro Series currently focuses on three models: Pro5, Pro12, and Pro16. That makes it easier to understand: choose Pro5 for smaller harsh-environment tasks, Pro12 for mid-payload work, and Pro16 when more payload and reach are needed.

Applications

The JAKA Pro Series is suited to industrial tasks where both cobot flexibility and environmental protection are useful. Official JAKA pages list application areas including welding, loading and unloading, handling, polishing and grinding, packing, and palletizing. The Pro16 page also specifically points to heavier tasks such as palletizing, machine tending, polishing, grinding, and welding.

In practical terms, the Pro Series is a good fit when a business wants a collaborative robot arm but does not want to use a lightly protected model in a harsh or messy workspace. For example, welding and grinding areas may involve dust, particulates, sparks, or residue. Loading and unloading may involve repetitive interaction with machines or production lines. Palletizing may need longer reach and higher payload, which makes the Pro16 the more suitable option within this series.

The Pro Series is not necessarily the first choice for every cobot application. If the environment is clean and the task is simple, another JAKA series may be enough. But when protection and durability are central to the decision, the Pro Series becomes one of the more relevant JAKA options.

JAKA Pro Series Model Comparison

Model: JAKA Pro5
Payload: 5 kg | Reach: 954 mm | Robot Weight: 23 kg | Repeatability: ±0.02 mm | IP Rating: IP68 | Footprint: 158 mm
Best suited for: Compact harsh-environment tasks such as welding, polishing and grinding, loading and unloading, and handling where a 5 kg cobot is enough.

Model: JAKA Pro12
Payload: 12 kg | Reach: 1327 mm | Robot Weight: 41 kg | Repeatability: ±0.03 mm | IP Rating: IP68 | Footprint: 188 mm
Best suited for: Mid-payload harsh-environment work such as welding, machine tending, loading and unloading, handling, and polishing and grinding.

Model: JAKA Pro16
Payload: 16 kg | Reach: 1713 mm | Robot Weight: 79.7 kg | Repeatability: ±0.03 mm | IP Rating: IP68 | Footprint: 246 mm
Best suited for: Heavier and longer-reach harsh-environment work such as palletizing, machine tending, loading and unloading, welding, and polishing and grinding.
